Vitacci PENTORA HUNTER 200 EFI Utility ATV
Electronic Fuel Injection • Oil + Air Cooling System • Hydraulic Brakes • Compact Utility Platform • Rack Equipped
The Vitacci Pentora Hunter 200 EFI ATV is a compact utility-class off-road machine designed for riders who want dependable performance, lighter handling control, and practical hauling capability in a maneuverable platform. Featuring electronic fuel injection, oil-cooled engine support with forced-air assist, hydraulic braking, and integrated rack storage, the Pentora Hunter 200 delivers reliable performance across trails, ranch property, and recreational riding environments.
With its balanced chassis geometry, chain-drive system, and independent hydraulic damping, this ATV is ideal for entry-level utility riders and property-use applications.
ENGINE
Engine Type: Four-Stroke Single Cylinder Horizontal Engine
Cooling System: Oil Cooling + Forced Air Cooling
Fuel System: Electronic Fuel Injection (EFI)
Engine Model: JN1P63QMK
Displacement: 177.3cc
Rated Power: 7 kW @ 7,000 RPM
Maximum Power: 7.3 kW @ 7,500 RPM
Maximum Torque: 10 Nm @ 6,000 RPM
Compression Ratio: 10:1
Starting System: Electric Start
Ignition System: CDI
Designed for efficient throttle response and dependable trail riding torque delivery.
TRANSMISSION & DRIVE SYSTEM
Transmission Type: Automatic Centrifugal Dry Clutch
Drive System: Chain Drive
Provides smooth engagement and lightweight drivetrain operation for controlled maneuverability.
SUSPENSION SYSTEM
Front Suspension: Hydraulic Damper Suspension
Rear Suspension: Hydraulic Damper Suspension
Front Shock Length: 345 mm
Rear Shock Length: 350 mm
Supports stability and comfort across uneven riding terrain.
BRAKING SYSTEM
Front Brakes: Hydraulic Disc
Rear Brakes: Hydraulic Disc
Brake Control System:
Front Hand Brake
Rear Foot Brake
Provides reliable stopping performance during trail and utility riding.
DIMENSIONS & CAPACITY
Vehicle Size: 1860 × 1050 × 1340 mm
Wheelbase: 1210 ± 20 mm
Ground Clearance: 265 ± 15 mm
Seat Height: 835 ± 15 mm
Chassis Height: 295 mm
Handlebar Height: 1120 mm
Minimum Turning Diameter: 3400 ± 500 mm
Net Weight: 197 kg
Shipping Weight: 225 kg
Rated Load Capacity: 100 kg
Fuel Tank Capacity: 9.7 Liters
WHEELS & TIRES
Front Tires: 21×7-10
Rear Tires: 22×10-10
Rim Size: 10-inch Wheels
Tire Pressure:
Front: 9 PSI
Rear: 9 PSI
Designed for traction across dirt paths, trails, and light-duty utility terrain.
UTILITY FEATURES
Front Cargo Rack
Rear Cargo Rack
Passenger Backrest Support System
Hydraulic Brake System
Chain Drive Utility Platform
Compact structure supports both trail maneuverability and property-use flexibility.
ELECTRICAL & DISPLAY
Battery: 12V 9Ah
Headlights: 12V 55/55W
Spark Plug Options:
NGK C7HAS
A7T
A7RT
Provides dependable electrical starting and lighting performance.
PERFORMANCE SPECIFICATIONS
Maximum Speed: 60 km/h
Climbing Ability: 21°
Parking Stability Grade: ≥18%
Braking Distance: ≤5.9 m @ 30 km/h
Noise Rating: ≤82 dB(A)
Emission Rating:
CO ≤2%
HC ≤250 ppm
Engineered for efficient performance and controlled operating stability.
QUICK SPEC SUMMARY
Engine: 177.3cc EFI
Cooling System: Oil + Forced Air Cooling
Transmission: Automatic Centrifugal Clutch
Drive Type: Chain Drive
Start System: Electric Start
Fuel Tank: 9.7L
Front Tires: 21×7-10
Rear Tires: 22×10-10
Ground Clearance: 265 mm
Top Speed: 60 km/h
Load Capacity: 100 kg
IMPORTANT RIDER & DELIVERY INFORMATION
👉🏽 AGE REQUIREMENT: (G16) Recommended for riders 16 years old and up
👉🏽 ASSEMBLY REQUIRED: This unit ships crated in a factory box and requires setup before operation. Assembly typically includes handlebars, wheels (if applicable), battery connection, mirrors, racks, and inspection prior to riding.
👉🏽 OFF-ROAD USE NOTICE: This ATV is designed for off-road use only unless otherwise stated. Always check your local state and city regulations before operating on public roads or streets.
👉🏽 FREIGHT DELIVERY INFORMATION:
This vehicle ships via a freight carrier and delivery is made to the customer’s driveway or curbside depending on location accessibility. Someone must be available to receive and inspect the shipment at time of delivery.
👉🏽 INSPECTION UPON DELIVERY:
Please inspect packaging and unit condition at delivery and note any visible damage with the freight carrier before signing.
